GAF10 Series Automatic Liquid filling Line 1KG To 10KG

Page view
[Abstract]:
Liquid Filling Machine
Automatic Liquid Filling Line
Bottle Filling Machine
5 Liter Filling Machine

GAF-10 Series Automatic Filling Capping And Machine

Barrel Filling Line From 1KG To 10KG

Main Parameters
Division
Filling capacity
Air supply
Filling accuracy
5g/10g
120-180 barrels/Hr
0.5~0.7 Mpa
≤ 0.05% F.S.
Nozzle mateial
Power supply
Ex grade
Filling range
SUS304 / SUS316/PTFE
AC110~380V 50/60HZ 0.1KW
ExdllBT6(Optional)
1~10kg
     Applicable  field
 Medicine/Chemical/Food Industry /High cleanliness requirement /Light corrosive degree material etc.
  Applicable Materials
 General materials /Coating / Paint/Resins /Curing agents /lubricants / Diluents /Inks /Paints /Detergents /Edible oil /Chemicals etc.
   Functions   Cutover
Net weight/gross weight, automatic/manual function mode switchable
Optional Configuration
1.Filling pump 2.Return valve 3.Filter 4.Gas-collecting cover 5.Filling nitrogen device 6.Other customization
Suitable Barrel Type
Feature

        Our GAF-10series liquid filling machine is weighing scale built-in type filling machine , it has the obvious advantages of high accuracy and efficiency.

         Professional designed nozzle and valve to control the liquid filling speed , set big,medium,small three shift speed , accuracy is control within 0.05% Full Scale.With our own patented nozzle , no dripping absolutly, our machines reduce the material loss and cost, improve the safety and working environment.



Comparison with other series of our machine
Series
         GAF-10           (Current Series)
         GAF-30
GAF-300
GAF-1000
Air
0.5-0.7Mpa
0.5-0.7Mpa
0.5-0.7Mpa
0.5-0.7Mpa
Fill Range
1-10kg
10-30kg
100-300kg
100-1500kg
Division
5/10g
10/20g
0.1kg
0.1/0.2kg
Accuracy
<=0.05% F.S.
<=0.05% F.S.
<=0.05% F.S.
<=0.05% F.S.
Fill Head Material
SUS304/316/PTFE (Optional)
 SUS304/316/PTFE (Optional)
SUS304/316/PTFE (Optional)
SUS304/316/PTFE (Optional)
Ex Grade
ExdllBT6(Optional)
ExdllBT6(Optional)
ExdllBT6(Optional)
ExdllBT6(Optional)
